This alarm will occur when the GCB feedback input does not match the
expected position given by the GCB Close/Open output. It stays active until
the mismatch between the output and feedback persists.
ï‚· If there was no command issued by the controller and the breaker
(feedback) changes suddenly the position itself, the alarm will be
issued immediately.
ï‚· The alarm will be also issued if the breaker does not respond to an
open or close command within 2 seconds. If synchronizing is
disabled (binary input ForwSyncDisabl is active) the maximum
allowed reaction time is increased to 5.
This alarm will occur when the MCB feedback input does not match the
expected position given by the MCB Close/Open output. It stays active until
the mismatch between the output and feedback disappears.
ï‚· If there was no command issued by the controller and the breaker
(feedback) changes suddenly the position itself, the alarm will be
issued immediately.
ï‚· Self-opening of the breaker is not considered a fault and if all mains
values are within limits, the command to reclose the breaker is
issued after delay given by the setpoint MainsReturnDel has
elapsed.
ï‚· The alarm will be also issued, if the breaker does not respond to the
close command within 2 seconds. After this period has elapsed the
output MCB Close/Open is deactivated again and the next attempt
to close the breaker will occur first after the alarm is reset.
ï‚· The alarm will be also issued if the breaker does not respond to the
open command within 2 seconds. The output MCB Close/Open will
stay deactivated. Closing of GCB is blocked until this alarm
becomes inactive.
ï‚· If reverse synchronizing is disabled (binary input RevSyncDisable is
active) the maximal allowed reaction time is increased to 5.
