Dell PowerConnect 3548 User Manual

Configuring System Information 127
Displaying the Remote Log Servers Table:
1 Open the Remote Log Server Settings page.
2 Click Show All .
The
Log Servers Table page opens.
Figure 6-25. Log Servers Table
Removing a Log Server from the Log Servers Table Page:
1 Open the Remote Log Server Settings page.
2 Click Show All .
The
Log Servers Table page opens.
3 Select a Log Servers Table entry.
4 Select the Remove check box to remove the server(s).
5 Click Apply Changes .
The
Log Servers Table entry is removed, and the device is updated.
Working with Remote Server Logs Using the CLI Commands
The following table summarizes the equivalent CLI command for working with remote log servers.
Table 6-18. Remote Log Server CLI Commands
CLI Command Description
logging (ipv4-address|ipv6-addres |
hostname} [port port] [severity level]
[facility facility] [description text]
Logs messages to a remote server.
no logging Deletes a syslog server.
show logging Displays the state of logging and the syslog
messages.

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
