Dell PowerConnect 3548 User Manual

Viewing Statistics 419
• Frames Transmit — Indicates the number of EAPOL frames transmitted via the port.
•
Start Frames Receive — Indicates the number of EAPOL Start frames received on the port.
•
Log off Frames Receive — Indicates the number of EAPOL Logoff frames received on the port.
•
Respond ID Frames Receive — Indicates the number of EAP Resp/Id frames received on the port.
•
Respond Frames Receive — Indicates the number of valid EAP Response frames received on the port.
•
Request ID Frames Transmit — Indicates the number of EAP Req/Id frames transmitted via the port.
•
Request Frames Transmit — Indicates the number of EAP Request frames transmitted via the port.
•
Invalid Frames Receive — Indicates the number of unrecognized EAPOL frames that have been
received on this port.
•
Length Error Frames Receive — Indicates the number of EAPOL frames with an invalid Packet Body
Length received on this port.
•
Last Frame Version — Indicates the protocol version number attached to the most recently received
EAPOL frame.
•
Last Frame Source — Indicates the source MAC address attached to the most recently received
EAPOL frame.
Displaying EAP statistics for a port
1 Open the EAP Statistics page.
2 Select an interface in the Interface field.
The interface EAP statistics are displayed.
To reset the EAP Statistics
1 Open the EAP Statistics page.
2 Click Reset All Counters .
The EAP statistics counters are reset.
Viewing EAP Statistics Using the CLI Commands
The following table summarizes the CLI commands for viewing EAP statistics.
Table 8-4. EAP Statistics CLI Commands
CLI Command Description
show dot1x statistics Displays 802.1X statistics for the
specified interface.

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
