430 Viewing Statistics
The following is an example of the CLI commands:
Viewing the RMON Events Log
The RMON Events Log page contains a list of RMON events. To open the RMON Events Log page,
click Statistics/RMON→ RMON→ Events Log in the tree view.
Figure 8-11. RMON Events Log
The RMON Events Log page contains the following fields:
• Event — The RMON Events Log entry number.
•
Log No. — The log number.
•
Log Time — Time when the log entry was entered.
•
Description — Describes the log entry.
console(config)# rmon event 1 log
console(config)# exit
console# show rmon events
Index Description Type Community Owner Last Time Sent
----- ----------- -------- --------- ------- --------------
1 Errors Log CLI Jan 18 2002
23:58:17
2 High
Broadcast
Log-Trap router Manager Jan 18 2002
23:59:48

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
