72 Using Dell OpenManage Switch Administrator
Using the Switch Administrator Buttons
This section describes the buttons found on the OpenManage Switch Administrator interface. Interface
buttons are divided into the following categories:
Information Buttons
Information buttons provide access to online support and online help, as well as information about the
OpenManage Switch Administrator interfaces.
Device Management Buttons
Device Management buttons provide an easy method of configuring device information, and include
the following:
Table 5-3. Information Buttons
Button Description
Support Opens the Dell Support page at support.dell.com
Help Online help that contains information to assist in configuring and managing the
device. The online help pages are context-sensitive. For example, if the IP Addressing
page is open, the help topic for that page displays when Help is clicked.
About Contains the version and build number and Dell copyright information.
Log Out Opens the Log Out window.
Table 5-4. Device Management Buttons
Button Description
Apply Changes Applies set changes to the device.
Add Adds information to tables or dialogs.
Telnet Starts a Telnet session.
Query Queries tables.
Show All Displays the device tables.
Left arrow/Right Arrows Moves information between lists.
Refresh Refreshes device information.
Reset All Counters Clears statistic counters.
Print Prints the Network Management System page and/or table information.
Draw Creates statistics charts on-the-fly.
Details Shows further details relevant to the current page.
Back Returns to the previous page.

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
