318 Configuring Switch Information
4
Select a table entry.
5
Select the
Remove
check box.
6
Click
Apply Changes
.
The selected static address is deleted, and the device is updated.
Configuring Static Address Parameters Using CLI Commands
The following table summarizes the equivalent CLI commands for configuring static address parameters
as displayed in the Static MAC Address page.
The following is an example of the CLI commands.
Viewing Dynamic Addresses
The Dynamic Address Table contains information for querying information in the dynamic address
table, including the interface type, MAC addresses, VLAN, and table sorting. Packets forwarded to an
address stored in the address table are forwarded directly to those ports. The Dynamic Address Table
page also contains information about the aging time before a dynamic MAC address is erased, and
includes parameters for querying and viewing the Dynamic Address list. The Current Address Table
contains dynamic address parameters by which packets are directly forwarded to the ports.
Table 7-16. Static Address CLI Commands
CLI Command Description
bridge address mac-address [permanent | delete-on-
reset | delete-on-timeout | secure] {ethernet interface
| port-channel port-channel-number}
Adds a static MAC-layer station source address to the
bridge table.
show bridge address-table [vlan vlan] [ethernet
interface | port-channel port-channel-number]
Displays entries in the bridge-forwarding database.
console(config-if)#bridge address 00:60:70:4C:73:FF permanent
ethernet g8
console# show bridge address-table
Aging time is 300 sec
vlan mac address port type
---- ------------ ---- --------
1
00:60:70:4C:73:FF
1/e8
dynamic
1
00:60:70:8C:73:FF
1/e8
dynamic
200
00:10:0D:48:37:FF
1/e9
static
