364 Configuring Switch Information
Removing a MAC to VLAN Binding:
1 Open the Bind MAC to VLAN page.
2 Click Show All . The MAC to VLAN Table opens.
3 Select the desired VLAN, or select All to see bindings for all VLANs.
4 Select the Remove checkbox next to the desired bindings.
5 Click Apply Changes .
Binding MAC address to VLAN using CLI commands:
The following table summarizes the equivalent CLI commands for binding MAC addresses to VLAN.
The following is an example of the CLI commands:
console(config-vlan)# mac-to-vlan 0060.704c.73ff 123
console(config-vlan)# exit
console(config)# exit
console# show vlan mac-to-vlan
MAC Address VLAN
------------ ------
0060.704c.73ff 123
Defining VLAN Protocol Groups
The Protocol Group page provides parameters for configuring frame types to specific protocol groups.
To open the Protocol Group page, click Switch → VLAN → Protocol Group in the tree view.
Table 7-29. Binding MAC address to VLANs CLI Commands
CLI Command Description
mac-to-vlan mac-address vlan-id
Binds the MAC address to the VLAN.
switchport access vlan dynamic Configures private VLANs.
show mac-to-vlan Displays the MAC to VLAN database
no mac-to-vlan mac-address
Unbinds the MAC address from the VLAN.

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
