Dell PowerConnect 3548 User Manual

270 Configuring Switch Information
Displaying the Multiple Hosts Table
1 Open the Multiple Hosts page.
2 Click Show All .
The
Multiple Hosts Table opens.
Figure 7-4. Multiple Hosts Table
The Multiple Hosts Table displays the following additional field:
• Unit No. — Selects a stacking member.
Enabling Multiple Hosts Using the CLI Commands
The following table summarizes the equivalent CLI commands for enabling the advanced port based
authentication as displayed in the Multiple Hosts page.
The following is an example of the CLI Command.
Table 7-2. Multiple Hosts CLI Commands
CLI Command Description
dot1x multiple-hosts Allows multiple hosts (clients) on an 802.1X-
authorized port that has the dot1x port-control
interface configuration command set to auto.
dot1x single-host-
violation {forward
|discard |discard-
shutdown}[trap
seconds]
Configures the action to be taken when a station,
whose MAC address is not the client (supplicant)
MAC address, attempts to access the interface.
Console(config)# interface ethernet 1/e1
Console(config-if)# dot1x multiple-hosts

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
