Dell PowerConnect 3548 User Manual

272 Configuring Switch Information
Displaying the Authenticated Users Table
1 Open the Authenticated Users page.
2 Click Show All .
The
Authenticated Users Table opens.
Figure 7-6. Authenticated Users Table
Authenticating Users Using the CLI Commands
The following table summarizes the equivalent CLI commands for authenticating users as displayed in
the Authenticated Users page.
The following is an example of the CLI commands:
console# show dot1x users
Port Username Session Time Auth Method MAC Address
-----------------------------------------------------------------
1/e11 gili 00:09:27 Remote 00:80:c8:b9:dc:1d
Table 7-3. Add User Name CLI Commands
CLI Command Description
show dot1x users [username username] Displays 802.1X users for the device.

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
