Configuring Switch Information 287
3 In the Bind ACL to an Interface field, select a port or LAG.
4 Click Apply Changes .
The ACL is bound to the interface.
Displaying the ACL Bindings Table:
1 Open the Network Security - ACL Binding page.
2 Click Show All.
The ACL Bindings Table opens.
Figure 7-14. ACL Bindings Table
Copying ACL Parameters Between Interfaces
1 Open the Network Security - ACL Binding page.
2 Click Show All. The ACL Bindings Table opens.
3 In the Copy Parameters from field, select a Port or LAG from which you want to copy ACL settings.
4 In the table, check the Copy to checkbox for each entry to which you want to copy the settings.
5 Click Apply Changes .
Removing ACL Bindings
1 Open the Network Security - ACL Binding page.
2 Click Show All. The ACL Bindings Table opens.
3 In the table, check the Remove checkbox for each binding you want to remove.
4 Click Apply Changes .

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
