Dell PowerConnect 3548 User Manual

Configuring Switch Information 323
Copying Parameters in the GARP Timers Table
1 Open the GARP Timers page.
2 Click Show All .
The
GARP Timers Table opens.
Figure 7-34. GARP Timers Table
3 Select the interface in the Copy Parameters from field from either the Port or LAG drop-down menu.
The definitions for this interface are copied to the selected interfaces. See step 4.
4 Select the Copy to check box to define the interfaces to which the GARP timer definitions
(copied from
Copy Parameters from field) are copied, or click Select All to copy the definitions to
all ports or LAGs.
5 Click Apply Changes .
The parameters are copied to the selected ports or LAGs in the
GARP Timers Table , and the device
is updated.

Dell PowerConnect 3548 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 257 x 43.2 mm
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	48
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
