Dell PowerConnect 8024 User Manual

402 Configuring iSCSI Optimization
Default iSCSI Optimization Values
Table 17-1 shows the default values for the iSCSI optimization feature.
Table 17-1. iSCSI Optimization Defaults
Parameter Default Value
iSCSI Optimization Global Status Enabled
iSCSI CoS mode Disabled
Jumbo Frames Disabled
Spanning-tree Portfast Disabled
Unicast Storm Control Disabled
Classification iSCSI packets are classified by VLAN
instead of by DSCP values.
VLAN Priority tag iSCSI flows are assigned by default the
highest 802.1p VLAN priority tag mapped
to the highest queue not used for the voice
VLAN.
DSCP When DSCP is selected as the
classification, iSCSI flows are assigned by
default the highest DSCP tag mapped to
the highest queue not used for the voice
VLAN.
Remark Not enabled
iSCSI Session Aging Time 10 minutes
iSCSI Optimization Target Ports iSCSI well-known ports 3260 and 860 are
configured as default (with no IP address or
name) but can be removed as any other
configured target.

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
