Configuring Port and System Security 477
How Does the Authentication Server Assign DiffServ Filters?
The PowerConnect 8000/8100-series switches allow the external 802.1X
Authenticator or RADIUS server to assign DiffServ policies to users that
authenticate to the switch. When a host (supplicant) attempts to connect to
the network through a port, the switch contacts the 802.1X authenticator or
RADIUS server, which then provides information to the switch about which
DiffServ policy to assign the host (supplicant). The application of the policy
is applied to the host after the authentication process has completed.
For additional guidelines about using an authentication server to assign
DiffServ policies, see "Configuring Authentication Server DiffServ Filter
Assignments" on page 503.
What is the Internal Authentication Server?
The Internal Authentication Server (IAS) is a dedicated database for localized
authentication of users for network access through 802.1X. In this database,
the switch maintains a list of username and password combinations to use for
802.1X authentication. You can manually create entries in the database, or
you can upload the IAS information to the switch.
If the authentication method for 802.1X is IAS, the switch uses the locally
stored list of username and passwords to provide port-based authentication to
users instead of using an external authentication server. Authentication using
the IAS supports the EAP-MD5 method only.
Supplicant
Timeout
Port State: Deny Port State: Deny
Port/Client
Authenticated
on Guest VLAN
Delete Guest
VLANID through
Dot1Q
Port State: Deny Port State: Permit
VLAN: Default PVID
of the port
NOTE: The IAS database does not handle VLAN assignments or DiffServ policy
assignments.
Table 20-1. IEEE 802.1X Monitor Mode Behavior (Continued)
Case Sub-case Regular Dot1x Dot1x Monitor Mode
