518 Configuring Access Control Lists
How Are ACLs Configured?
To configure ACLs, follow these steps:
1
Create a MAC ACL by specifying a name.
2
Create an IP ACL by specifying a number.
3
Add new rules to the ACL.
4
Configure the match criteria for the rules.
5
Apply the ACL to one or more interfaces.
Preventing False ACL Matches
Be sure to specify ACL access-list, permit, and deny rule criteria as fully as
possible to avoid false matches. This is especially important in networks with
protocols such as FCoE that have newly-introduced EtherType values. For
example, rules that specify a TCP or UDP port value should also specify the
TCP or UDP protocol and the IPv4 or IPv6 EtherType. Rules that specify an
IP protocol should also specify the EtherType value for the frame.
In general, any rule that specifies matching on an upper-layer protocol field
should also include matching constraints for each of the lower-layer protocols.
For example, a rule to match packets directed to the well-known UDP port
number 22 (SSH) should also include matching constraints on the IP
protocol field (protocol=0x11 or UDP) and the EtherType field (EtherType=
0x0800 or IPv4). Figure 21-1 lists commonly-used EtherTypes numbers:
NOTE: The actual number of ACLs and rules supported depends on the
resources consumed by other processes and configured features running on the
switch.
Table 21-1. Common EtherType Numbers
EtherType Protocol
0x0800 Internet Protocol version 4 (IPv4)
0x0806 Address Resolution Protocol (ARP)
0x0842 Wake-on LAN Packet
0x8035 Reverse Address Resolution Protocol (RARP)
0x8100 VLAN tagged frame (IEEE 802.1Q)
