Dell PowerConnect 8024 User Manual

540 Configuring Access Control Lists
periodic { days-of-the-
week time
} to {[ days-of-
the-week
] time }
Configure a recurring time entry for the named time
range.
• days-of-the-week —The first occurrence indicates the
starting day(s) the ACL goes into effect. The second
occurrence is the ending day(s) when the ACL rule is no
longer in effect. If the end
days-of-the-week are the same
as the start, they can be omitted
This variable can be any single day or combinations of
days:
Monday , Tu e sd a y , Wednesday , Thursday , Friday ,
Saturday , Sunday . Other possible values are:
– daily -- Monday through Sunday
– weekdays -- Monday through Friday
–
weekend -- Saturday and Sunday
•
time — Time the ACL rule starts going into effect (first
occurrence) or ends (second occurrence). The time is
expressed in a 24-hour clock, in the form of
hours:minutes.
CTRL + Z Exit to Privileged EXEC mode.
show time-range [
name ] View information about all configured time ranges,
including the absolute/periodic time entries that are
defined for each time range. Use the
name variable to view
information about the specified time range.
Command Purpose

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
