Setups Introduction
The GNX4 is equipped with four inputs and four outputs that can be configured several different ways for
both live and recording applications. These settings determine which pair of outputs the mic,line,and guitar
processing are routed to and how the mic or line inputs are routed through the GNX4’s effects
processing.
Output Setups and Speaker Compensation
The GNX4 features both 1/4” and XLR outputs on the rear panel. These jacks let you simultaneously
connect the GNX4 to an amplifier/speaker system on stage via the 1/4” outputs and connect directly to
your PA system via the XLR outputs. The GNX4 incorporates Speaker Compensation filtering that can
be turned on or off independently for each output pair depending on your application needs.
Use the OUTPUT SETUP button along with the DATA WHEEL to select one of the Output Setup
options.
The six Output Setups are as follows:
steroall - All input sources (guitar, mic, line,drums, onboard 8-track recorder playback and USB
playback) are routed to both output pairs in stereo. Speaker Compensation can be turned
on and off independently for either the 1/4" or XLR outputs using the Speaker
Compensation switch associated with each pair on the rear panel.
