Select and Adjust the Reverb
In our example preset we wanted a little bit of Hall Reverb to provide some ambience. To add the
reverb,do the following:
1. Press the EFFECT SELECT DOWN button until the LED in the Reverb row lights.
2. If the display reads off (Of),press the STATUS button until the display reads on (On).
3. Rotate Knob 1 to select Hall (
Hall) for the Reverb Type.
4. Rotate Knob 2 to set the Reverb Predelay to
2.
5. Rotate Knob 3 to set the Reverb Decay to
15.
6. Rotate Knob 4 to set the Reverb Damping to
40.
7. Rotate Knob 5 to set the Reverb Level to
30.
Store the Preset
The last step is to store our changes to a User Preset. If we changed presets or turned the GNX4 off
without storing these settings,it would forget what we had done and revert back to the original preset.
To store the preset, do the following:
1. Press STORE. The first letter in the display begins to flash. Since this is an example preset,let’s name
the preset
examplE.
2. Rotate the DATA WHEEL until the flashing character in the display is an
E.
3. Press the NEXT button once and the second character begins to flash.
4. Rotate the DATA WHEEL again until the flashing character is an
X. Continue using the Next Arrow
button to select the character location and the DATA WHEEL to change the characters.
5. Once the Display reads
exampLE,press STORE again.The numbers in the red numeric display are
flashing.
6. Rotate the DATA WHEEL to select 48 as the destination.
7. Press STORE once more to save the preset.
Congratulations! You have successfully created a Preset.
1. Press the Store
3. Use the Next Arrow Button
2. Use Data Wheel to
1. Press Effect
lights.
2. Press the Status Button to
turn the Reverb on.
3. Rotate Knob 1
type.
4. Rotate Knob 2
PreDelay to 2.
5. Rotate Knob 3
Decay to 15.
7. Rotate Knob 5
Level to 30.
6. Rotate Knob 4
Damping to 40.
To Next Page
