DigiTech GNX4 User Manual

Applying Power
Before applying power to anything,set your amp(s) to a clean tone and set the tone controls to a flat EQ
response (on most amps,this would be 0 or 5 on the tone controls). Then do the following:
1.Turn your amp volume all the way down.
2.Pull the mixer’s master faders all the way down.
3.Turn the GNX4’s Output Level knobs all the way down (fully counter-clockwise).
4.Connect the plug of the PSS3 power supply to the GNX4’s Power Jack. Connect the other end of the
PSS3 power supply to an AC outlet.
5.Turn the GNX4’s power on.
6.Turn your amplifier(s) on and adjust the volume(s)to a normal playing level.
7.Push the mixer’s master faders up to the desired listening level.
8.Gradually increase the GNX4’s Output Levels to the desired listening level.
3. Turn the GNX4's Ouput
