17 Appendix
538
Appendix
17
Specifications
This section lists the main specifications of the machine. Note that the specifications
and the appearance of the product may change without prior notice.
îš„Copy Feature Specifications
Type Console
Copying method Laser xerography
Scan resolution 600×600 dpi (23.6×23.6 dots/mm)
Output resolution 600×600 dpi (23.6×23.6 dots/mm)
Gradation 256 levels
Warm-up time Copier only model:
15 seconds or less (at 20 °C room temperature)
Copier/printer model:
21 seconds or less (at 20 °C room temperature)
Copier/fax or copier/fax/printer model:
24 seconds or less (at 20 °C room temperature)
Important • The value may vary depending on the machine
configuration.
Copy document The maximum size is 297×432 mm (A3, 11×17") for both sheets
and books.
Development method Dry development (dual component)
Document table type Fixed
Photosensitive type OPC
Fusing system Heat roller
Scanning method Flatbed scanning using CCD image sensor
Copy (sheet) size [Trays 1 - 4]
Maximum: A3 (297×420 mm), Tabloid (11x17")
Minimum : A5 (148×210 mm)
[Bypass tray]
Maximum: A3 (297x420mm), Tabloid (11x17")
Minimum : Postcard (100×148 mm), Envelope (120×235 mm)
Non-standard size: X direction 99 to 432 mm, Y direction 89 to
297 mm
(When copying both sides of non-standard size paper, specify
the size within the range from 127 to 432 mm for the X direction
and from 89 to 297 mm for the Y direction.
Image loss width:Top edge, 4 mm or less; bottom edge, 4 mm
or less; left and right edges, 4 mm or less
Important • If the X (width) of non-standard size paper is less than 140
mm, documents may not be printed properly.
Copy paper Paper Tray 1 : 60 - 105g/m
2
Paper Trays 2 to 4 : 60 - 216g/m
2
Paper Tray 5 (Bypass): 60 - 216g/m
2
Important • The use of paper recommended by Fuji Xerox is suggested.
Copying may not be performed correctly depending on the
conditions.
To Next Page
