Fuji Xerox DocuCentre-II 3005 User Manual

HP-GL2 Emulation
571
Appendix
17
Printable Area
The printable area in the HP-GL mode is as follows.
Paper Size and Printable Area
Note • The HP-GL emulation supports 5 paper sizes: A3,A5,A4, B4 and B5.
Note • The HP-GL emulation supports 5 paper sizes: A3,A5,A4, B4 and B5.
Paper
size
Paper Length
(1/7200 inch)
Coordinate Value (1/7200 inch)
X Axis Y Axis Margin Printable Area Top-right Edge Margin
Width Height
Bottom
-left X
Bottom
Left Y
Long
Side
Short
Side
Top-
right X
Top-
right Y
XR YU
A3 119052 84168 1260 1260 116532 81648 117792 82908 1260 1260
A4 84168 59508 1260 1260 81648 56988 82908 58248 1260 1260
A5 59508 41940 1260 1260 56988 39420 58248 40680 1260 1260
B4 103176 72828 1260 1260 100656 70308 101916 71568 1260 1260
B5 72828 51588 1260 1260 70308 49068 71568 71568 1260 1260
Paper
size
Paper Length
(1/7200 inch)
Coordinate Value (1/7200 inch)
X Axis Y Axis Margin Printable Area Top-right Edge Margin
Width Height
Bottom
-left X
Bottom
Left Y
Long
Side
Short
Side
Top-
right X
Top-
right Y
XR YU
A3 84168 119052 1260 1260 81648 116532 82908 117792 1260 1260
A4 59508 84168 1260 1260 56988 81648 58248 82908 1260 1260
A5 41940 59508 1260 1260 39420 56988 40680 58248 1260 1260
B4 72828 103176 1260 1260 70308 100656 71568 101916 1260 1260
B5 51588 72828 1260 1260 49068 70308 50328 71568 1260 1260
Width
Short-side
YU
Long-side
Bottom-left X, Bottom-left Y
(0, 0)
XR
Height
Actual Paper
Printable Area
Top-right X, Top-right Y
