PRIMERGY TX150 S4 User’s Guide
4
Manual OS Installation
4.3 Installing the LAN Driver
This section explains the procedure for installing the driver.
In addition to the case where the OS is installed manually, the driver must be installed
when a LAN card is added.
4.3.1 Installing the LAN Driver (Windows Server 2003 x64)
LAN cards except PG-2861 are recognized as the network adapters when the OS is installed.
Perform "
■ Updating the LAN Cards" (Jpg.133) on all LAN device names under [Network adapters] ,
and then perform "
■ Installing the LAN Driver" (Jpg.134) on the ethernet controllers under [Other
devices].
` For the following LAN cards, the network adapters are recognized when the cards are mounted during
OS installation.
• PG-1852
• PG-1892
■ Updating the LAN Cards
Perform the following procedures on all LAN device names under [Network adapters] in [Device
Manager].
1 Click [Start] → [Administrative Tools] → [Computer Manager].
2 Click [Device Manager].
3 Double-click a LAN device name under [Network adapters].
` Names of the LAN devices are displayed as follows.
4 Insert the driver disk created from the ServerStart CD-ROM into the server.
5 Click [Update Driver] in the [Driver] tab window.
The "Welcome to the Hardware Update Wizard" window appears.
6 Check [No, not this time] and click [Next].
table: LAN device name
LAN cards LAN device name
Onboard LAN (1000BASE-T) Broadcom NetXtreme Gigabit Ethernet
PG-1852 Intel(R) PRO/1000 MT Desktop Adapter
PG-1892 Intel(R) PRO/1000 MT Server Adapter
To Next Page
