Chapter 8 Configuring Hardware and Utilities
8.3.2 Main Menu
The [Main] menu is displayed when you start the SCSI Setup Utility.
Use the [↓] [↑] [←] [→] keys to move the cursor to the menu where you want to change settings and
press the [Enter] key. The selected menu appears.
table: Items on the Main Menu
Item Description
Adapter Displays the name of the SCSI controller. On this server, "1020/1030" is displayed.
PCI Bus Displays the number of the PCI bus where the SCSI controller is connected.
Dev/Func Displays the PCI device/function of the SCSI controller. The five upper bits
represent the device and the three lower bits represent the function.
Port Number Displays the I/O port address of the SCSI controller.
IRQ Displays the IRQ (IRQ level) of the SCSI controller.
NVM Displays whether or not the SCSI controller has NVRAM for storing settings. On
this server, "Yes" is displayed.
Boot Order Displays the boot order of SCSI controllers. When the server starts up, startable
SCSI devices connected to SCSI controllers are searched for in ascending
numerical order.
SCSI devices start up in order of detection.
LSI Logic Control Displays whether or not the SCSI controller can use standard device drivers.
RAID Status Displays the array status when the array system is configured.
LSI Logic MPT SCSI Setup Utility Version MPT BIOS-IME-x.xx.xx
<Boot Adapter List> <Global Properties>
LSI Logic Host Bus Adapters
Adapter PCI Dev/ Port IRQ NVM Boot LSI Logic RAID
Bus Func Number Order Control Status
<1020/1030 2 40> 3000 11 Yes 0 Enabled --
<1020/1030 2 41> 3400 9 Yes 1 Enabled --
F1 =HELP
Esc=Abort/Exit
F2 =Menu
ArrowKeys=Select Item
Home/End=Select Item
-/+ =Change [Item]
Enter=Excute <Item>
