24
Chapter 1 Overview
e Maintenance switch
This switch is used only by maintenance personnel. Do not touch this.
f System status LED ( )
This LED lights or blinks in amber when an error is detected in the server components. If this
LED lights or blinks, contact an office listed in the "Contact Information" of "Start Guide".
g Hard disk access LED ( )
This LED blinks when data is being written to or read from the hard disk.
h Power LED ( )
This LED is lit green when the server is turned on.
` Power LED is lit when the server is in standby mode (when the AC power is on and the DC
power is off), but this does not indicate an error.
i Power switch
Press this switch to turn the server on.
` Do not turn the server off when the hard disk access LED is blinking.
Data in the hard disk may be damaged.
j 5-inch storage bay
Contains a 5-inch internal device.
Unlike external devices, an internal option does not need to be connected to the outlet because its
power is supplied from the server. It also saves space.
k CD-ROM drive
Reads data or programs from a CD-ROM.
l CD-ROM eject button
Press this button to eject a CD-ROM.
Do not press this when the CD-ROM access LED is on.
m CD-ROM access LED
This LED blinks when data is being read from a CD-ROM.
n Drive cover
This slides up and down.
o Floppy disk eject button
Press this button to eject a floppy disk.
Do not press this when the floppy disk access LED is on.
p Floppy disk access LED
This LED blinks when data is being written to or read from a floppy disk.
q Floppy disk drive
Writes/reads data to/from a floppy disk.
r USB connector ( )
Connects peripheral equipment conforming to the USB standard (2.0 or 1.1).
