243
PRIMERGY TX150 S4 User’s Guide
8
Configuring Hardware and utilities
8.3.5 Adapter Properties
Detailed configuration information of SCSI adapters on the SCSI bus is set. Press the [F2] key from the
[Main] menu window, select [Adapter] and press the [Enter] key to display the window.
table: Items on the Adapter Properties Window
Item Setting Description
Device Properties
Displays "
■ Device Properties Submenu" (Jpg.244) window. Configures settings
on device options.
RAID Properties
Displays "
■ RAID Properties Submenu" (Jpg.244) window. Configures settings
on the array system with onboard SCSI controller.
Host SCSI ID 7 (Unchangeable) Specifies the SCSI ID of the SCSI controller.
SCSI Bus Scan Order Low to High (0..Max)
(Unchangeable)
Specifies the SCSI device scan order during the
startup.
Removable Media Support None (Unchangeable) Sets whether or not the SCSI Setup Utility supports
removable disk units such as MO drives.
CHS Mapping SCSI Plug and Play
Mapping (Unchangeable)
Specifies the mapping method of CHS information.
Spinup Delay (Secs) • 2 (Initial value)
• 1–15
Specifies the boot interval of devices.
Secondary Cluster Server No (Unchangeable) Sets whether to enable or disable the secondary
cluster server.
Termination Control Auto (Unchangeable) Sets SCSI bus termination.
Restore Defaults Reads default values for the controller.
LSI Logic MPT SCSI Setup Utility Version MPT BIOS-IME-x.xx.xx
Adapter Properties
Adaapter PCI DEV/
Bus Func
1020/1030 2 40
1020/1030 2 41
<Device Properties>
<RAID Properties><Synchronize Whole Mirror>
F1 =HELP
Esc=Abort/Exit
ArrowKeys=Select Item
Home/End=Select Item
-/+ =Change [Item]
Enter=Excute <Item>
Host SCSI ID
SCSI Bus Scan Order
Removable Media Support
CHS Mapping
Spinup Delay(Secs)
Secondary Cluster Server
Termination Control
<Restore Defaults>
[ 7]
[Low to High(0..Max)]
[None]
[SCSI Plug and Play Mapping]
[ 2]
[No]
[Auto]
To Next Page
