Chapter 8 Configuring Hardware and Utilities
■ Console Redirection Submenu
This submenu configures detailed settings for console redirection.
table: Items on the Console Redirection Menu
Item Setting Description
Console Redirection • Disabled (Initial value)
•Enabled
Sets whether to enable or disable console redirection.
When set to [Enabled] the following parameters
appear. Set each of them. If set to [Disabled], the
items are not displayed.
Media Type • Serial (Initial value)
•LAN
Sets the connection type for console redirection.
Port • Serial1 (Initial value)
• Serial2
Sets the serial port to be used for console redirection.
Baud Rate • 1200
• 2400
• 4800
• 9600 (Initial value)
• 19.2K
• 38.4K
• 57.6K
•115.2K
Sets the speed of the console redirection connection
(in bps).
Protocol • VT100
• VT100,8bit
• PC-ANSI,7bit
• PC-ANSI
• VT100+ (Initial value)
Sets the console type for console redirection.
Flow Control • None
• XON/XOFF
• CTS/RTS (Initial value)
Sets flow control for console redirection.
Mode • Standard
• Enhanced (Initial value)
Sets the range of use for console redirection.
To Next Page
