5–14 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL

CHAPTER 5: SETTINGS

programmable messages can be created and displayed (message scratchpad). For

example, the relay can alternately scan a motor identification message, the current in

each phase, and the hottest stator RTD. Default messages are shown in this subgroup.

Use the following procedure to add default messages:

1. Enter the correct passcode for the S1 469 SETUP Z PASSCODE Z ENTER PASSCODE FOR

ACCESS settings (unless the passcode has already been entered or the passcode

is “0”, defeating the passcode security feature).

2. Move to the message to be added to the default message list using the

MESSAGE T and MESSAGE S keys. The selected message can be any actual

value or Message Scratchpad message.

3. Press ENTER. The message

PRESS [ENTER] TO ADD DEFAULT MESSAGES will

be displayed for 5 seconds.

4. Press ENTER again while displayed to add the current message to the default

message list.

5. If the procedure was followed correctly, the

DEFAULT MESSAGE HAS BEEN

ADDED

flash message will be displayed:

6. To verify that the message was added, view the last message in the

S1 469 SETUP

ZV DEFAULT MESSAGES subgroup.

Use the following procedure to remove default messages:

1. Enter the correct passcode for the S1 469 SETUP Z PASSCODE Z ENTER PASSCODE FOR

ACCESS settings (unless the passcode has already been entered or unless the

passcode is “0”, defeating the passcode security feature).

2. Select the message to remove under the

S1 469 SETUP ZV DEFAULT MESSAGES sub-

group.

3. When the default message to be removed is shown, press ENTER. The relay dis-

plays the

PRESS [ENTER] TO REMOVE DEFAULT MESSAGE message.

4. Press ENTER to remove the current message from the default message list.

5. If the procedure was followed correctly, the following flash message will be dis-

played:

5.2.6 Message Scratchpad

PATH: SETTINGS Z S1 469 SETUP ZV MESSAGE SCRACTHPAD

DEFAULT MESSAGE

HAS BEEN REMOVED



MESSAGE [

TEXT 1
