CHAPTER 6: ACTUAL VALUES
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 6–29
The values in this menu reflect the RTD names as programmed If no RTDs are programmed
in
S8 RTD TEMPERATURE, the THIS FEATURE NOT PROGRAMMED flash message will
appear when an attempt is made to enter this group of messages.
6.4.4 Analog Input Min/Max
PATH: ACTUAL VALUES ZV A3 LEARNED DATA ZV ANALOG IN MIN/MAX
The 469 will learn the minimum and maximum values of the analog inputs since they were
last cleared. This information can be cleared with the
S1 469 SETUP ZV CLEAR DATA ZV
CLEAR ANALOG I/P MIN/MAX settings. When the data is cleared, the present value of each
analog input will be loaded as a starting point for both minimum and maximum. The name
of the input and the units will reflect those programmed for each input.
The values shown here reflect the programmed analog input names. If no Analog Inputs
are programmed in
S12 ANALOG I/O, the THIS FEATURE NOT PROGRAMMED flash
message appears when an attempt is made to enter this group of messages.
 ANALOG
INPUT [Z]
MIN/MAX
ANALOG I/P 1
MIN: O Units
Range: –50000 to 50000
MESSAGE
ANALOG I/P 1
MAX: 0 Units
Range: –50000 to 50000
MESSAGE
ANALOG I/P 2
MIN: O Units
Range: –50000 to 50000
MESSAGE
ANALOG I/P 2
MAX: 0 Units
Range: –50000 to 50000
MESSAGE
ANALOG I/P 3
MIN: O Units
Range: –50000 to 50000
MESSAGE
ANALOG I/P 3
MAX: 0 Units
Range: –50000 to 50000
MESSAGE
ANALOG I/P 4
MIN: O Units
Range: –50000 to 50000
MESSAGE
ANALOG I/P 4
MAX: 0 Units
Range: –50000 to 50000
