2–14 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 2: INTRODUCTION
PRODUCTION TESTS
Thermal cycling: .............................................operational test at ambient, reducing to –40°C and then
increasing to 60°C
Dielectric strength: .......................................1.9 kV AC for 1 second, or 1.6 kV AC for 1 minute, per UL
508.
DO NOT CONNECT FILTER GROUND TO SAFETY GROUND DURING ANY PRODUCTION
TESTS!
2.2.9 Certification
CERTIFICATION
ACA:.......................................................................conforms to RF emissions for Australia, tick mark
CE:..........................................................................conforms to EN 55011/CISPR 11, EN 50082-2
EN: .........................................................................EN50263 EMC - CE for Europe
FCC:.......................................................................conforms to RF emissions for North America, part 15
IEC:.........................................................................conforms to 1010-1, LVD - CE for Europe
ISO: ........................................................................Manufactured under an ISO9001 registered system.
UL:..........................................................................UL listed E83849 for the USA and Canada
GE Multilin Temperature Cycling –50°C / +80°C
IEC 60068-2-38 Composite Temperature/Humidity 65/–10°C at 93% RH
IEC 60255-5 Dielectric Strength 2300 V AC
IEC 60255-5 Impulse Voltage 5 kV
IEC 60255-5 Insulation Resistance >100 MΩ / 500 V AC / 10 s
IEC 60255-21-1 Sinusoidal Vibration 2 g
IEC 60255-22-1 Damped Oscillatory Burst, 1 MHz 2.5 kV / 1 kV
IEC 60255-22-2 Electrostatic Discharge: Direct 8 kV
IEC 60255-22-3 Radiated RF Immunity 10 V/m
IEC 60255-22-4 Electrical Fast Transient / Burst Immunity 4 kV
IEC 60255-22-5 Surge Immunity 4 kV / 2 kV
IEC 60255-22-6 Conducted RF Immunity, 150 kHz to 80 MHz 10 V/m
IEC 60255-25 Radiated RF Emission Group 1 Class A
IEC 60255-25 Conducted RF Emission Group 1 Class A
IEC 60529 Ingress of Solid Objects and Water (IP) IP40 (front), IP20 (back)
IEC 61000-4-11 Voltage Dip; Voltage Interruption 0%, 40%, 100%
IEEE C37.90.1 Fast Transient SWC ±4 kV
IEEE C37.90.1 Oscillatory Transient SWC ±2.5 kV
IEEE C37.90.3 Electrostatic Discharge: Air and Direct 15 kV / 8 kV
Standard Test Name Level
