CHAPTER 6: ACTUAL VALUES
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 6–7
6.2.4 Alarm Status
PATH: ACTUAL VALUES Z A1 STATUS ZV ALARM STATUS
 ALARM
STATUS [Z]
NO ALARMS
Range: N/A. Message seen when no
alarms are active
MESSAGE
REMOTE ALARM
STATUS: Active
Range: Active, Latched
MESSAGE
PRESSURE SWITCH
ALARM STATUS:
Range: Active, Latched
MESSAGE
VIBRATION SWITCH
ALARM STATUS:
Range: Active, Latched
MESSAGE
DIG. COUNTER
ALARM:
Range: 1 to 9999999999. Displays
current value of digital counter
MESSAGE
TACHOMETER
ALARM: 3000 RPM
Range: 0 to 3600 RPM. Displays current
Tachometer Digital Input value
MESSAGE
GENERAL SW. A
ALARM STATUS:
Range: Active, Latched
MESSAGE
THERMAL CAPACITY
ALARM: 100% USED
Range: 1 to 100. Thermal Capacity
Used value is shown here
MESSAGE
XX.XX x FLA OVER-
LOAD
Range: 0 to 99999 s. Shows overload
level and estimated time to trip.
MESSAGE
UNDERCURRENT
ALARM
Range: 1 to 5000 A; 5 to 99% FLA.
Lowest phase current shown.
MESSAGE
CURRENT UNBALANCE
ALARM: 15%
Range: 0 to 100%. Reflects the present
unbalance level
MESSAGE
GROUND FAULT
ALARM: 25.3 A
Range: 0.1 to 5000 A. Reflects the
present ground current level
MESSAGE
STATOR RTD #1
ALARM: 135°C
Range: –50 to 250°C
MESSAGE
OPEN SENSOR
ALARM:
Range: RTD with the open sensor as
programmed for RTDs 1 to 12
MESSAGE
SHORT/LOW TEMP
ALARM
Range: 1 to 12. Shows RTD with the
short/low temperature alarm
MESSAGE
UNDERVOLTAGE
ALARM
Range: 0 to 20000 V; 50 to 99% of
Rated
MESSAGE
OVERVOLTAGE ALARM
Vab= 4992 V 120%
Range: 0 to 20000 V; 101 to 150% of
Rated
MESSAGE
SYSTEM FREQUENCY
ALARM: 59.4 Hz
Range: 0.00, 20.00 to 120.00 Hz
MESSAGE
POWER FACTOR
ALARM PF: 0.00
Range: 0.00 to 0.99 Lead or Lag, 0.00,
1.00
