GE 469 User Manual

CHAPTER 5: SETTINGS
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 5–93
5.13.2 Analog Inputs 1 to 4
PATH: SETTINGS ZV S12 ANALOG I/O Z ANALOG INPUT 1(4)
MWhrs 0.000 to 999999.999 MWhrs 0.001 50.000 100.000
Analog In Diff 1-2 –50000 to +50000 1 0 100
Analog In Diff 3-4 –50000 to +50000 1 0 100
Torque 0 to 999999.9 0.1 0 100
Table 5–3: Analog Output Parameter Selection Table
PARAMETER NAME RANGE / UNITS STEP DEFAULT
MIN. MAX

ANALOG [
ANALOG INPUT 1:
Disabled
Range: Disabled, 4-20 mA, 0-20 mA, 0-
1 mA
MESSAGE
ANALOG INPUT 1
NAME:
Range: 12 alphanumeric characters
MESSAGE
ANALOG INPUT 1
UNITS:
Range: 6 alphanumeric characters
MESSAGE
ANALOG INPUT 1
MINIMUM: 0
Range: –50000 to 50000 in steps of 1
MESSAGE
ANALOG INPUT 1
MAXIMUM: 100
Range: –50000 to 50000 in steps of 1
MESSAGE
BLOCK ANALOG
INPUT 1
Range: 0 to 5000 s in steps of 1
MESSAGE
ANALOG INPUT 1
ALARM: Off
Range: Off, Latched, Unlatched
MESSAGE
ASSIGN ALARM
RELAYS:
Range: Alarm, Alarm & Auxiliary2,
Alarm & Aux2 & Aux3, Alarm &
Auxiliary3, Auxiliary2, Aux2 &
Aux3, Auxiliary3
MESSAGE
ANALOG INPUT 1
ALARM
Range: –50000 to 50000 in steps of 1
Units reflect
ANALOG INPUT 1
UNITS
above
MESSAGE
ANALOG INPUT 1
ALARM
Range: Over, Under
MESSAGE
ANALOG INPUT 1
ALARM
Range: 0.1 to 300.0 s in steps of 0.1
MESSAGE
ANALOG INPUT 1
ALARM
Range: On, Off
MESSAGE
ANALOG INPUT 1
TRIP: Off
Range: Off, Latched, Unlatched
MESSAGE
ASSIGN TRIP
RELAYS:
Range: Trip, Trip & Auxiliary2, Trip &
Aux2 & Aux3 Trip & Auxiliary3

GE 469 Specifications

General

Model	GE 469
Category	Relays
Frequency	50/60 Hz
Protection Functions	Overcurrent
Communication Protocols	Modbus, DNP3, IEC 61850
Display	LCD
Mounting	Panel
