GE 469 User Manual

CHAPTER 5: SETTINGS
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 5–71
5.9.2 RTDs 1 to 6
PATH: SETTINGS ZV S8 RTD TEMPERATURE ZV RTD #1(6)
170 338 164.76 269.91 224.92 15.61
180 356 168.47 280.77 233.97 16.00
190 374 172.46 291.96 243.30 16.39
200 392 175.84 303.46 252.88 16.78
210 410 179.51 315.31 262.76 17.17
220 428 183.17 327.54 272.94 17.56
230 446 186.82 340.14 283.45 17.95
240 464 190.45 353.14 294.28 18.34
250 482 194.08 366.53 305.44 18.73
Table 5–2: RTD Temperature vs. Resistance
Temperature 100 Ω Pt
(DIN 43760)
120 Ω Ni 100 Ω Ni 10 Ω Cu
° C ° F
 RTD
#1 [Z]
RTD #1 APPLICA-
TION:
Range: Stator, Bearing, Ambient, Other,
None
MESSAGE
RTD #1 NAME:
Range: 8 alphanumeric characters
MESSAGE
RTD #1 ALARM:
Off
Range: Off, Latched, Unlatched
MESSAGE
ASSIGN ALARM
RELAYS:
Range: Alarm, Alarm & Auxiliary2,
Alarm & Aux2 & Aux3, Alarm &
Auxiliary3, Auxiliary2, Aux2 &
Aux3, Auxiliary3
MESSAGE
RTD #1 ALARM
TEMPERATURE:
Range: 1 to 250°C in steps of 1
MESSAGE
RTD #1 HIGH
ALARM:
Range: Off, Latched, Unlatched
MESSAGE
HIGH ALARM
RELAYS:
Range: Alarm, Alarm & Auxiliary2,
Alarm & Aux2 & Aux3, Alarm &
Auxiliary3, Auxiliary2, Aux2 &
Aux3, Auxiliary3
MESSAGE
RTD #1 HIGH ALARM
TEMPERATURE:
Range: 1 to 250 in steps of 1
MESSAGE
RTD #1 ALARM
EVENTS: Off
Range: On, Off
MESSAGE
RTD #1 TRIP:
Off
Range: Off, Latched, Unlatched
MESSAGE
RTD #1 TRIP VOT-
ING:
Range: RTD #1 to RTD #12
MESSAGE
ASSIGN TRIP
RELAYS:
Range: Trip, Trip & Auxiliary2, Trip &
Aux2 & Aux3, Trip & Auxiliary3
