5–74 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 5: SETTINGS
RTD. Trip voting has been added for extra reliability in the event of RTD malfunction. If
enabled, a second RTD must also exceed the trip temperature of the RTD being checked
before a trip will be issued. If the RTD is chosen to vote with itself, the voting feature is
disabled. The RTD name may be changed if desired.
5.9.5 RTD 12
PATH: SETTINGS ZV S8 RTD TEMPERATURE ZV RTD 12
RTDs 12 defaults to “Ambient” RTD type. There are individual alarm, high alarm and trip
configurations for this RTD. Trip voting has been added for extra reliability in the event of
RTD malfunction. If enabled, a second RTD must also exceed the trip temperature of the
RTD being checked before a trip will be issued. If the RTD is chosen to vote with itself, the
voting feature is disabled. The RTD name may be changed if desired.
 RTD
#12 [Z]
RTD #12 APPLICA-
TION:
Range: Stator, Bearing, Ambient, Other,
None
MESSAGE
RTD #12 NAME:
Range: 8 alphanumeric characters
MESSAGE
RTD #12 ALARM:
Off
Range: Off, Latched, Unlatched
MESSAGE
ASSIGN ALARM
RELAYS:
Range: Alarm, Alarm & Auxiliary2,
Alarm & Aux2 & Aux3, Alarm &
Auxiliary3, Auxiliary2, Aux2 &
Aux3, Auxiliary3
MESSAGE
RTD #12 ALARM
TEMPERATURE: 60°C
Range: 1 to 250°C in steps of 1
MESSAGE
RTD #12 HIGH
ALARM:
Range: Off, Latched, Unlatched
MESSAGE
HIGH ALARM
RELAYS:
Range: Alarm, Alarm & Auxiliary2,
Alarm & Aux2 & Aux3, Alarm &
Auxiliary3, Auxiliary2, Aux2 &
Aux3, Auxiliary3
MESSAGE
RTD #12 HIGH
ALARM
Range: 1 to 250°C in steps of 1
MESSAGE
RTD #12 ALARM
EVENTS: Off
Range: On, Off
MESSAGE
RTD #12 TRIP:
Off
Range: Off, Latched, Unlatched
MESSAGE
RTD #12 TRIP VOT-
ING:
Range: RTD #1 to RTD #12
MESSAGE
ASSIGN TRIP
RELAYS:
Range: Trip, Trip & Auxiliary2, Trip &
Aux2 & Aux3, Trip & Auxiliary3
MESSAGE
RTD #12 TRIP
TEMPERATURE: 80°C
Range: 1 to 250°C in steps of 1
