469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 3–1
469 Motor Management Relay
Chapter 3: Installation
Digital Energy
Multilin
Instal lation
3.1 Mechanical Installation
3.1.1 Description
The 469 is packaged in the standard GE Multilin SR-series arrangement, which consists of
a drawout unit and a companion fixed case. The case provides mechanical protection to
the unit and is used to make permanent connections to all external equipment. The only
electrical components mounted in the case are those required to connect the unit to the
external wiring. Connections in the case are fitted with mechanisms required to allow the
safe removal of the relay unit from an energized panel (for example, automatic CT
shorting). The unit is mechanically held in the case by pins on the locking handle that
cannot be fully lowered to the locked position until the electrical connections are
completely mated. Any 469 can be installed in any 469 case, except for custom
manufactured units that are clearly identified as such on both case and unit, and are
equipped with an index pin keying mechanism to prevent incorrect pairings.
No special ventilation requirements need to be observed during the installation of the unit.
The 469 can be cleaned with a damp cloth.
