CHAPTER 6: ACTUAL VALUES
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 6–33
6.6 A5 Event Recorder
6.6.1 Event 01 to Event 256
PATH: ACTUAL VALUES ZV A5 EVENT RECORDER ZV EVENT 01(256)
îš„ EVENT
01 [Z]
<Cause>
TIME OF EVENT 01:
00:00:00.0
Range: hour:minutes:seconds
MESSAGE
DATE OF EVENT 01:
Jan. 01, 1992
Range: month day, year
MESSAGE
MOTOR SPEED DUR-
ING
Range: High Speed, Low Speed. Seen if
two-speed feature is enabled.
MESSAGE
TACHOMETER DURING
EVENT01: 0 RPM
Range: 0 to 3600 RPM. Seen only if a
Digital Input is Tachometer.
MESSAGE
A: 0 B: 0
C: 0 A EVEN
Range: 0 to 100000 A
MESSAGE
MOTOR LOAD
EVENT01: 0.00 x
Range: 0.00 to 20.00 x FLA
MESSAGE
CURRENT UNBALANCE
EVENT01: 0%
Range: 0 to 100%
MESSAGE
GROUND CURRENT
EVENT01: 0.00 A
Range: 0.00 to 5000.0 A. Not seen if
Ground CT is set as None.
MESSAGE
A: 0 B: 0
C: 0 A Diff.
Range: 0 to 5000 A. Seen only if Phase
Differential CT is set.
MESSAGE
HOTTEST STATOR
RTD:
Range: –50 to 250°C, --- (no RTD). Seen
if at least 1 RTD is set as Stator.
MESSAGE
HOTTEST BEARING
RTD:
Range: –50 to 250°C, --- (no RTD). Seen
if at least 1 RTD is Bearing.
MESSAGE
HOTTEST OTHER
RTD:
Range: –50 to 250°C, --- (no RTD). Seen
if at least 1 RTD is set as Other.
MESSAGE
AMBIENT
RTD:
Range: –50 to 250°C, --- (no RTD). Seen
if at least 1 RTD is Ambient.
MESSAGE
Vab: 0 Vbc: 0
Vca: 0 A EVE
Range: 0 to 20000 A. Not seen if VT
Connection set as None
MESSAGE
Van: 0 Vbn: 0
Vcn: 0 A EVE
Range: 0 to 20000 A. Seen only if VT
Connection set as Wye.
MESSAGE
SYSTEM FREQUENCY
EVENT01: 0.00 Hz
Range: 0.00, 20.00 to 120.00 Hz. Not
seen if VT Connection is None.
MESSAGE
0kW0
kVA
Range: –50000 to 50000 kVA. Not seen
if VT Connection is set as None
To Next Page
