CHAPTER 6: ACTUAL VALUES
6.7 A6 Product Info
6.7.1 469 Model Information
PATH: ACTUAL VALUES ZV A6 PRODUCT INFO Z 469 MODEL INFORMATION
All of the 469 model information may be viewed here when the unit is powered up. In the
event of a product software upgrade or service question, the information shown here
should be jotted down prior to any inquiry.
6.7.2 Calibration Information
PATH: ACTUAL VALUES ZV A6 PRODUCT INFO ZV CALIBRATION INFORMATION
The date of the original calibration and last calibration may be viewed here.
 469
MODEL [Z]
INFORMATION
ORDER CODE:
469-P5-HI-A20-E
Range: Displays the relay order code
and installed options.
MESSAGE
469 SERIAL NO:
A3050001
Range: Displays the serial number of
the relay.
MESSAGE
FIRMWARE REVI-
SION:
Range: Displays the firmware revision
of the relay.
MESSAGE
BOOT REVISION:
3.00
Range: Displays the boot software
revision of the relay.
MESSAGE
HARDWARE REVI-
SION:
Range: Displays the hardware revision
of the relay.
MESSAGE
MOD NUMBER:
004
Range: Displays the relay modification
number.

CALIBRATION [
Z]
INFORMATION
ORIGINAL CALIBRA-
TION
DATE: Jan 01 1995
Range: month day year
MESSAGE
LAST CALIBRATION
DATE: Jan 01 1995
Range: month day year
