5.11.2 Power Factor
PATH: SETTINGS ZV S10 POWER ELEMENTS Z POWER FACTOR
If the 469 is applied on a synchronous motor, it is desirable not to trip or alarm on power
factor until the field has been applied. Therefore, this feature can be blocked until the
motor comes up to speed and the field is applied. From that point forward, the power
factor trip and alarm elements will be active. Once the power factor is less than either the
Lead or Lag level, for the specified delay, a trip or alarm will occur indicating a Lead or Lag
condition. The power factor alarm can be used to detect loss of excitation and out of step.

POWER [
BLOCK PF ELEMENT
FROM START: 1 s
Range: 0 to 5000 s in steps of 1
MESSAGE
POWER FACTOR
ALARM: Off
Range: Off, Latched, Unlatched
MESSAGE
ASSIGN ALARM
RELAYS:
Range: Alarm, Alarm & Auxiliary2,
Alarm & Aux2 & Aux3, Alarm &
Auxiliary3, Auxiliary2, Aux2 &
Aux3, Auxiliary3
MESSAGE
POWER FACTOR LEAD
ALARM LEVEL: Off
Range: 0.05 to 1.00 in steps of 0.01.
Enter 1.00 to turn feature off.
MESSAGE
POWER FACTOR LAG
ALARM LEVEL: Off
Range: 0.05 to 1.00 in steps of 0.01.
Enter 1.00 to turn feature off.
MESSAGE
POWER FACTOR
ALARM
Range: 0.2 to 30.0 s in steps of 0.1
MESSAGE
POWER FACTOR
ALARM
Range: On, Off
MESSAGE
POWER FACTOR
TRIP: Off
Range: Off, Latched, Unlatched
MESSAGE
ASSIGN TRIP
RELAYS:
Range: Trip, Trip & Auxiliary2, Trip &
Aux2 & Aux3, Trip & Auxiliary3
MESSAGE
POWER FACTOR LEAD
TRIP LEVEL: Off
Range: 0.05 to 1.00 in steps of 0.01.
Enter 1.00 to turn feature off.
MESSAGE
POWER FACTOR LAG
TRIP LEVEL: Off
Range: 0.05 to 1.00 in steps of 0.01.
Enter 1.00 to turn feature off.
MESSAGE
POWER FACTOR TRIP
DELAY: 1.0 s
Range: 0.2 to 30.0 s in steps of 0.1
