GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 8-2 Section 8-1 - Overview
Section 8-2 Top Cover
8-2-1 Disassembly/Assembly of Top Cover
Follow the steps below and refer Figure 8-1, For FRU Details refer 9-1-2
1.) Always Shut Down the System when disassembling the TOP COVER
2.) Disconnect the power cord from the mains and remove from the system.
3.) Remove Probe, which is at the right side of the base.
4.) Remove the probe holder.
5.) Remove two screws (a,b) at the side of the probe holder.
6.) Move the unit to the edge of the table and remove two screws (e,f) from the bottom of the unit.
7.) Remove the handle cap by pulling upward and remove the handle screws (c,d).
8.) Slide the top cover backward by holding the handle.
9.) For assembly follow the reverse order.
Service Manual
Section Functional Test/ Diagnostic Test Debrief Script
4-2-1 Power ON/ Boot up
Service manual direction 5305880-
100, Section 8-2-1.Equipment
passed all required tests and is
ready for use.
4-2-1 Power OFF/ Shut down
4-3 Functional Checks
Table 8-2 Functional tests
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 131 of 197
