GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 8-4 Section 8-3 - KEYBOARD
Section 8-3KEYBOARD
8-3-1 Detaching the Keyboard
Follow the steps below and refer Figure 8-2. For FRU Details refer 9-1-3
1.) Remove Front Panel. Refer 8-4-1.
2.) Remove 14-pin connector from the Davinci.
3.) Remove the black ground cable coming from the keyboard along with the 14 pin flat cable
connected to the chassis.
4.) Remove the TGC connector from the Davinci.
5.) Place a rubber mat below the unit and tilt the unit upward. Remove two screws (a,b) from
the bottom hinge of the keyboard and remove the bottom hinge cover refer
Figure 8-2.
6.) Press the lock release and turn the keyboard 90°. Move the keyboard downward and
carefully pull out the cable with the connector.
7.) Remove the 2 ring bushes refer Figure 8-2.
8.) For assembly follow the reverse order.
Service Manual
Section
Functional Test/ Diagnostic Test Debrief Script
4-2-1 Power ON/ Boot up
Service manual direction 5305880-
100, Section 8-3-1.Equipment
passed all required tests and is
ready for use.
4-2-1 Power OFF/ Shut down
4-3 Functional Checks
7-2-3 Keyboard Diagnostics tests
Table 8-3 Functional tests
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 133 of 197
