GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 8-14 Section 8-5 - PCBs
Section 8-5 PCBs
8-5-1 Disassembly/Assembly of Davinci Board.
Follow steps below and refer
1.) Remove Top Cover. Refer 8-2. For FRU Details refer 9-1-7 to
9-1-9
2.) For disassembling both Davinci Board and FEB Board together, remove all communications
and power cables from the Davinci board and FEB board.
3.) Remove two screws to detach the PCB Assembly from the chassis.
4.) Pull the Davinci and FEB boards upward.
5.) For Davinci Board only, remove four screws (four from the Davinci board) and detach the
Davinci board separately from the flush connector on the FEB.
6.) For assembly follow the reverse order.
Table 8-7 Functional tests
Service Manual
Section
Functional Test/ Diagnostic Test Debrief Script
4-2-1 Power ON/ Boot up
Service manual direction
5305880-100, Section 8-5-
1.Equipment passed all required
tests and is ready for use.
4-2-1 Power OFF/ Shut down
4-3 Functional Checks
4-5 Software configuration check
7-2 Diagnostics tests
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 143 of 197
