GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Chapter 9 - Replacement Parts Page 9-9
9-1-7 MATERIAL LIST - DAVINCI
OPERATOR CONSOLE ASSY
5304117,5304414,5304240,5304248,5304441,5304596,5306834.
1.) Davinci is common for PAL & NTSC, Only dip switch setting has to be changed for the required
type.
Figure 9-6 Davinci Board
601
Table 9-6 Davinci
Item Part Name Part No. Description Qty
601 Davinci Assy (PAL/NTSC) 5212995 LOGIQ™ 100 PRO 1
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 164 of 197
