Page 3-28 Section 3-7 - Paperwork
3-6-5 Video Specification
Video specifications may be needed to be able to connect laser cameras to the LOGIQ™ 100 PRO.
Section 3-7Paperwork
Note: During and after installation, the documentation (i.e. User Manuals, Installation Manuals...) for the
peripheral units must be kept as part of the original system documentation. This will ensure that all
relevant safety and user informations are available during the operation and service of the complete
system.
General
SL Parameter NTSC PAL
1 Total Number of Horizontal Lines
525[Frame] 625[Frame]
2 Vertical Field Frequency
60[Hz] 50[Hz]
3 Horizontal Scanning Frequency
15.734[kHz] 15.625[KHz]
4 Vertical Scanning Method
Interlaced Interlaced
5 Sync Input
Composite Composite
6 Pixel Clock
12.272715[MHz] 12.25[MHz]
7 Display width and Height [pixel * line]
608 X 464 608 X 472
Horizontal Timing & Video Amplitude
SL Parameter NTSC PAL
1 Total H-Line Time
63.556[micro sec.] 64.00[micro sec.]
2 H-Sync Pulse Width
4.725[micro sec.] 4.68[micro sec.]
3 Back Porch
4.725[micro sec.] 4.68[micro sec.]
4 Total Active H-line time
52.64[micro sec.] 52.07[micro sec.]
5 Front Porch
1.46[micro sec.] 1.49[micro sec.]
6 Video Amplitude (back porch to peak)
0.7Vpp 0.7Vpp
7 Sync Amplitude (back porch to peak)
0.3Vpp 0.3Vpp
Vertical Timing
SL Parameter NTSC PAL
1 Total V-Line Time
262.5[H] 312.5[H]
2 V-Sync Pulse Width
1st Field 3[lines] 1st Field 2.5[lines]
2nd Field 3[lines] 2nd Field 2.5[lines]
3 V-front porch
1st Field 7.5[lines] 1st Field 6.25[lines]
2nd Field 7.5[lines] 2nd Field 6.25[lines]
4 V-Blanking
1st Filed 30.5[lines] 1st Filed 32[lines]
2nd Field 30.5[lines] 2nd Field 32[lines]
