GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Chapter 3 - Installation Page 3-5
Section 3-3 Preparing for Installation
3-3-1 Physical Inspection
3-3-1-1 Systems Voltage Settings
• Verify that the scanner is set to the correct voltage.
The Voltage settings for the LOGIQ™ 100 PRO Scanner is found on a label on the rear of the
system.
WARNING CONNECTING A LOGIQ™ 100 PRO SCANNER TO THE WRONG VOLTAGE LEVEL
WILL MOST LIKELY DESTROY THE SCANNER.
3-3-1-2 Video Formats
Check that the video format is set to the locally used video standard, NTSC or PAL.
3-3-2 EMI Protection
This unit has been designed to minimize the effects of Electro Magnetic Interference (EMI). Many
of the covers, shields, and screws are provided primarily to protect the system from image artifacts
caused by this interference. For this reason, it is imperative that all covers and hardware are
installed and secured before the unit is put into operation.
Section 3-4 Assembling LOGIQ™ 100 PRO
CAUTION It is strongly recommended that the equipment should be installed on an even and hard
surface to provide proper cooling, as the vents for air circulation are on the bottom cover.
3-4-1 Installation of the System
1.) Locate, remove and unpack the probes located in the separate container.
2.) Make sure that system power is OFF before connecting or disconnecting the probe.
3.) Secure the probe to the receptacle as follows. Refer to Fig 3-4
a.) Ensure probe `twist lock' lever points towards the top of the probe connector.
a.) Install probe connector on the receptacle guide pin until it touches the receptacle mating
surface.
a.) Twist the probe connector `twist lock' lever in the clockwise direction to lock it in place
(Twist the lever anticlockwise direction to disconnect the probe).
4.) Connect the LOGIQ™ 100 PRO Power cable's female part to the power connector located on
the rear panel and the male part to a hospital grade power socket of a proper voltage. Never
use a three-to-two pin adapter; this defeats the purpose of safety ground.
5.) Unlock the keyboard by pressing the lock release on top of the system.
CAUTION Do not move or lift the unit, holding the keyboard alone.
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 50 of 197
