GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Chapter 3 - Installation Page 3-21
3-6-2-1 Power Supply
The Following Power Line requirement should be monitored one week before Installation. We
recommend that a Drantez model 605-3 Power line Monitor with options 101 to be used
3-6-2-2 Facility Power Socket
A separate power outlet with a 5 amp circuit breaker for 120/220 VAC is recommended. The specific
power receptacle used depends on the country's power line standards.
This receptacle should have International Electro technical Commission (IEC) approval, or
equivalent
3-6-2-3 Storage & Operation Requirements
The LOGIQ™ 100 PRO is shipped in a single container excluding probes. Shipping weight is
approximately 12 kgs.
Table 3-7 Table provides a summary of temperature, atmospheric pressure,
and humidity tolerances for shipping, installation and operation:
3-6-3 Optional Peripherals
LOGIQ™ 100 PRO peripherals and accessories can be properly connected using the connectors
on the rear panel of the LOGIQ™ 100 PRO system.
External Optional Peripherals
• VCR (Sony SVO-9500MD)
• VGP (Sony UP-895MD/MDW and UPD-897MDW)
• Printing through Laser Jet Printer with HP LaserJet 1020 Plus.
• Images can be transfered to memory stick from the image archive.
Table 3-6
Parameter Limits
Voltage Range
USA, JAPAN
Europe
100-115VAC ± 10% (90-127VAC)
200-240VAC ± 10% (198-264VAC)
Power
USA, JAPAN
Europe
MAX 145VA
MAX 175VA
Line Frequency All Applications
50/60Hz ± 2Hz
Power Transients
Less than 25% of nominal peak voltage for less than 1 millisecond for any type of
transient, including line frequency, synchronous, asynchronous or periodic transients
Decaying Oscillation
Less than 15% of Peak Voltage for less than 1 millisecond
Table 3-7 Storage & Operation Requirements
Parameter Storage Operation
Temperature (Deg.C) -10 to 60 10-40
Atmospheric Pressure
(hPa)
700 to 1060 700 to 1060
Humidity (%)
Non- Condensing
30 to 90 35 to 75
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 66 of 197
