IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 1-6 Section 1-1 - Overview
1-3-3 Product Icons
The following table describes the purpose and location of safety labels and other important
information provided on the equipment.
LABEL/SYMBOL PURPOSE/MEANING LOCATION
Identification and Rating Plate Manufacturer's name and
address
Date of manufacture
Model and serial numbers
Electrical ratings
Rear of console near power
inlet
Type/Class Label Used to indicate the degree of
safety or protection.
IP Code (IPX8) Indicates the degree of
protection provided by the
enclosure per IEC 529. IPX8
indicates drip proof.
Footswitch
Equipment Type BF (man in
the box symbol) IEC 878-02-
03 indicates B Type
equipment having a floating
applied part.
Probe connectors and PCG
connector
Equipment Type CF (heart in
the box symbol) IEC 878-02-
05 indicates equipment
having a floating applied part
having a degree of protection
suitable for direct cardiac
contact.
ECG connector and surgical
probes
Device Listing/Certification
Labels
Laboratory logo or labels
denoting conformance with
industry safety standards
such as UL or IEC.
Rear of console
CAUTION - This unit
weighs...Special care must be
used to avoid..."
This precaution is intended to
prevent injury that may result
if one person attempt to move
the unit considerable
distances or on an incline due
to the weight of the unit.
On the console where easily
seen during transport?
"DANGER - Risk of explosion
used in..."
The system is not designed
for use with flammable
anesthetic gases.
Rear of console
Table 1-5 Product Icons
