1-4-6 Dangerous Procedure Warnings
Warnings, such as the example below, precede potentially dangerous procedures throughout this
manual. Instructions contained in the warnings must be followed.
1-4-7 Lockout/Tagout Requirements (For USA Only)
Follow OSHA Lockout/Tagout requirements by ensuring you are in total control of the plug.
1-4-8 Classification
Type of protection against electric shock: Class I EQUIPMENT *1
Degree of protection against electric shock: Type BF EQUIPMENT**2
1.) *Class I EQUIPMENT
EQUIPMENT in which protection against electric shock does not rely on BASIC
INSULATION only, but which includes an additional safety precaution in that means
are provided for the connection of the EQUIPMENT to the protective earth conductor
in the fixed wiring of the installation in such a way that ACCESSIBLE METAL PARTS
cannot become LIVE in the event of a failure of the BASIC INSULATION.
2.) **Type BF EQUIPMENT*
Type B EQUIPMENT with a F-TYPE isolated applied part providing a degree of
protection against electric shock to such a degree that the allowable PATIENT
LEAKAGE CURRENT under SINGLE FAULT CONDITIONS is not exceeded when
1.1 times the highest rated MAINS VOLTAGE is applied between the APPLIED PART
and earth.
DANGEROUS VOLTAGES, CAPABLE OF CAUSING DEATH, ARE PRESENT IN
THIS EQUIPMENT. USE EXTREME CAUTION WHEN HANDLING, TESTING AND
ADJUSTING.
EXPLOSION WARNING: DO NOT OPERATE THE EQUIPMENT IN AN EXPLOSIVE
ATMOSPHERE. OPERATION OF ANY ELECTRICAL EQUIPMENT IN SUCH AN
ENVIRONMENT CONSTITUTES A DEFINITE SAFETY HAZARD.
DO NOT SUBSTITUTE PARTS OR MODIFY EQUIPMENT: BECAUSE OF THE DANGER
OF INTERDICTING ADDITIONAL HAZARDS, DO NOT INSTALL SUBSTITUTE PARTS OR
PERFORM ANY UNAUTHORIZED MODIFICATION OF THE EQUIPMENT.
DANGER
WARNING
WARNING
