GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 8-10 Section 8-4 - FRONT PANEL/MONITOR
Section 8-4 FRONT PANEL/MONITOR
8-4-1 Disassembly/Assembly of Front Panel
Follow steps below and refer Figure 8-6 For FRU Details refer 9-1-5
1.) Remove Top Cover. Refer 8-2
2.) Lock the Keyboard before removing the front panel.
3.) Remove the keyboard connector from the Davinci Board.
4.) Remove the black ground cable coming from the keyboard .
5.) Remove Brightness and Contrast connector from the Brightness and Contrast PCB. (Refer
Detail 2 in the
8-11)
6.) Remove two screws (e,f) and detach the bottom hinge of the keyboard.
7.) Remove two screws (a,b) from the base along the rib.
8.) Remove two screws (c,d) from the support plate on the chassis.
9.) Disconnect the connector coming from the POWER ON Switch.
10.) Slide the front panel and keyboard sub-assembly together.
11.) For assembly follow the reverse order.
Table 8-5 Functional tests
Service Manual
Section
Functional Test/ Diagnostic Test Debrief Script
4-2-1 Power ON/ Boot up
Service manual direction 5305880-
100, Section 8-4-1.Equipment
passed all required tests and is
ready for use.
4-2-1 Power OFF/ Shut down
4-3 Functional Checks
7-2 Diagnostics tests
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 139 of 197
