GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Chapter 10 - Quality Assurance Page 10-9
10-5-2-2 Peripheral/Option Checks
If any peripherals or options are not part of the system configuration, the check can be omitted.
Refer to the User Manual for a list of approved peripherals/options.
10-5-3 Input Power
10-5-3-1 Mains Cable Inspection
10-5-4 Cleaning
10-5-4-1 General Cleaning
Step Item Description
1 VCR
Verify record/playback capabilities of the VCR. Clean heads and covers if necessary.
2
VGP
Printer
Verify hardcopy output of the video graphic printer. Clean heads and covers if necessary.
3
B/W
Printer
Verify hardcopy output of the B/W printer. Clean heads and covers if necessary.
4 Footswitch
Verify that the footswitch is functioning as programed. Clean as necessary.
Table 10-8 GE Approved Peripheral/Hardware Option Functional Checks
Step Item Description
1
Unplug
Cord
Disconnect the mains cable from the wall and system.
2 Inspect
Inspect it and its connectors for damage of any kinds.
3 Verify
Verify that the LINE, NEUTRAL and GROUND wires are properly attached to the terminals, and that no
strands may cause a short circuit.
4 Verify
Inlet connector retainer is functional.
Table 10-9 Mains Cable Inspection
Step Item Description
1 Console
Use a fluid detergent in warm water on a soft, damp cloth to carefully wipe the entire system. Be careful
not to get the cloth too wet so that moisture does not enter the console.
2
Probe
Holder
Clean probe holders. (they may need to be soaked to remove excess gel).
Table 10-10 General Cleaning
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 180 of 197
