IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 10-6 Section 10-3 - Periodic Maintenance Schedule
10-4-2 Special Tools, Supplies and Equipment
10-4-2-1 Specific Requirements for Periodic Maintenance
See Chapter 7
21045C Close Quarter Saw 9-52723 #8 Tap
9-44604 Wrench, Adj 10 inch High Speed Drill Set
9-41587 Screwdriver 5/16 inch x 8 inch #36 Drill
9-41586 Screwdriver, Stubby 5/16 inch #29 Drill
9-GH19512 Countersink 1/2 inch 9-44046 3/8 inch Socket Set
9-44741 12 PC Combination Wrench Set
GE-2 Sears Kit (#99034)
Tool ID Description Tool ID Description
Table 10-4 Overview of GE-2 Tool Kit Contents (Continued)
Tool Part Number Comments
Digital Volt Meter (DVM)
Electric Safety Analyzer DALE
600
46-285652G1 For 120V Unit
Electric Safety Analyzer DALE
600E
46-328406G2 For 220V Units
Leakage Current Ultrasound Kit 2113015 For 120V and 220V Units
Anti Static Kit
46–194427P231
46–194427P279
46–194427P369
46–194427P373
46–194427P370
Kit includes anti–static mat, wrist strap and cables for 200 to
240 V system
3M #2204 Large adjustable wrist strap
3M #2214 Small adjustable wrist strap
3M #3051 conductive ground cord
Anti Static Vacuum Cleaner
46–194427P278
46–194427P279
120V
230V
Safety Analyzer 46–285652G1
DALE 600 KIT (or equivalent) for electrical tests
SVHS VCR Cassette
E7010GG
E7010GF
60 minute
120 minute
SVHS VCR Head Cleaner
See VCR user manual for requirements
B/W Printer Cleaning Sheet
See printer user manual for requirements
Disposable Gloves
Table 10-5 Overview of Requirements for Periodic Maintenance
