GE MEDICAL SYSTEMS
D
IRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-1
Chapter 8
Replacement Procedures
Section 8-1
Overview
8-1-1 Purpose of Chapter 8
This chapter describes replacement procedures for the following modules and subsystems.
Section 8-2
DISASSEMBLY/RE-ASSEMBLY
Section Description Page Number
8-1 Overview 8-1
8-2 DISASSEMBLY/RE-ASSEMBLY 8-1
8-3 Monitor 8-2
8-4 Keyboard Block 8-15
8-5 Covers 8-39
8-6 Body Block 8-70
8-7 PCB Boards 8-89
8-8 PC Block 8-101
8-9 Power Block 8-153
8-10 Software Loading Procedure 8-166
8-11 Installing Base Software Load Image 8-178
8-12 Full Backup / Restore Procedure 8-202
Table 8-1 Contents in Chapter 8
WARNINGWARNING
ONLY QUALIFIED SERVICE PERSONNEL SHOULD REMOVE ANY COVERS OR
PANELS. ELECTRICAL HAZARDS EXISTS AT SEVERAL POINTS INSIDE. BECOME
THOROUGHLY FAMILIAR WITH ALL HAZARDOUS VOLTAGES AND HIGH CURRENT
LEVELS TO AVOID ACCIDENTAL CONTACT
CAUTION
Do not wear the ESD wrist strap when you remove a part of power supply unit. Turn OFF power
and unplug the power cord before removing a part of power supply unit. However be sure to turn
off power and wear the strap before you remove a circuit boards.
WARNINGWARNING
DO NOT SERVICE OR DISASSEMBLE PARTS UNDER FRU UNIT LEVEL AT ANY
CIRCUMSTANCES.
