GE MEDICAL SYSTEMS
DIRECTION 2300000, REVISION 1 LOGIQ™ 5 SERVICE MANUAL
1-6 Section 1-2 - Important Conventions
"CAUTION - Dangerous voltage" (the lightning
flash with arrowhead in equilateral triangle) is
used to indicate electric shock hazards.
Various
"Mains OFF" Indicates the power off position of
the mains power switch.
Rear of system adjacent to mains switch
"OFF/Standby" Indicates the power off/
standby position of the power switch.
CAUTION
This Power Switch DOES NOT ISOLATE
Mains Supply
Adjacent to On-Off/Standby Switch
"Mains ON" Indicates the power on position of
the mains power switch.
"ON" Indicates the power on position of the
power switch.
CAUTION
This Power Switch DOES NOT ISOLATE
Mains Supply
Front Panel Switch
"Protective Earth" Indicates the protective
earth (grounding) terminal.
Internal
"Equipotentiality" Indicates the terminal to be
used for connecting equipotential conductors
when interconnecting (grounding) with other
equipment.
Rear of console
Table 1-5 Product Icons (Continued)
LABEL/SYMBOL PURPOSE/MEANING LOCATION
